Soft closing, under mount, full extension, 6 way adjustable
Cabinet Sides
Finished, skins are not required
Shipping
Leaves the warehouse in 5-7 business days Order delivery depends on your location. Usually orders arrive in 3-6 business days after leaving the warehouse. Read more
The detailed cabinet specifications including cabinet sizes, specific parts dimensions, height, width, and other information are below. Please note cabinet specifications vary depending on the particular cabinet line.
General specifications
Color
Cream with brown glaze
Finish
UV coating paint
Door and drawer profile
Raised panel
Wood species
Birch
Sides color
Matches cabinet front, no skins required.
Overlay
Full overlay
Drawer slides
Soft closing, under mount, full extension, 6 way adjustable. VideoPicture
Door hinges
Euro-style, soft closing, concealed, 6 way adjustable. Video
Interior color
Clear coated natural wood color. Glass door cabinets come with a matching (same as cabinet front) interior color.
Toe kick color
Matches cabinet front
Particle board
No particle board is used in this cabinet line construction
Doors and drawer fronts
3/4" thick HDF (High Density Fiberboard) with wood veneer door and drawer front frame and center panel. Doors and drawer fronts are 5-piece construction. Why do we use MDF?
Side, top, and bottom panels
1/2" thick furniture grade plywood with wood veneer. Side, top, and bottom panels are dadoed into the face frame.
Back panel
1/2" thick furniture grade plywood with wood veneer, full height, solid. Back panel is dadoed into side panels.
3/4" thick furniture grade plywood with wood veneer, adjustable
Shelf pins
Metal
Toe kick thickness
1/2"
Base corner supports
Wood corner braces
Center stile
No center stile on wall and base cabinets up to 42" wide
Door and drawer stoppers
Clear adhesive bumpers
Hinge side
Hinges on single door wall and base cabinets are located on the right side by default. In most cases, they can be reversed to the opposite side. Reversing the cabinet hinge position may require pre-drilling small holes.
Cabinets with full overlay doors come with a small clearance between doors/drawers and cabinet edges. If a cabinet is located next to a wall or other surface (e.g. refrigerator panel), we recommend adding at least 1/4" additional clearance to allow doors/drawers operate smoothly. The 1/4" is the minimum recommended, however, some applications will require a bigger clearance depending on hardware and other project requirements. Use a scribe molding or wall/base fillers to fill the gaps. Generally, the additional spacing is not required in between cabinets unless they are different depth (e.g. a 12" deep wall cabinet next to a 24" deep pantry). See an example
About Specifications
Specifications are subject to change without notice. Certain dimensions are rounded to the nearest 1/8". Contact us with any questions about cabinet styles and specifications.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Diagonal wall corner cabinet with 1 door and 2 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide.
Diagonal wall corner cabinet with 1 door and 2 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide.
Diagonal wall corner cabinet with 1 door and 2 shelves. This cabinet takes up 27" of space on each side of the corner. The visible cabinet front part is approximately 17" wide. We recommend using this type of cabinets in applications where the corner wall cabinet is higher than the surrounding units and a crown molding is installed on all wall cabinets. See the product page for more details.
Diagonal wall corner cabinet with 1 door and 3 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide.
Diagonal wall corner cabinet with 1 door and 3 shelves. This cabinet takes up 27" of space on each side of the corner. The visible cabinet front part is approximately 17" wide. We recommend using this type of cabinets in applications where the corner wall cabinet is higher than the surrounding units and a crown molding is installed on all wall cabinets. See the product page for more details.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 28"-31". It can be used as left or right, requires a wall filler (not included). The door section is 14-1/2" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 28"-31". It can be used as left or right, requires a wall filler (not included). The door section is 14-1/2" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 3 shelves. This cabinet takes up more space than its width, the recommended space is 28"-31". It can be used as left or right, requires a wall filler (not included). The door section is 14-1/2" wide. See the product page for an installation diagram example.
Wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion.
Wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion.
Wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion.
Wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion.
Wall stacker cabinet with 2 glass doors and matching color cabinet interior. This cabinet is available with the glass doors only. It does not include glass inserts.
Wall stacker cabinet with 2 glass doors and matching color cabinet interior. This cabinet is available with the glass doors only. It does not include glass inserts.
Wall stacker cabinet with 2 glass doors and matching color cabinet interior. This cabinet is available with the glass doors only. It does not include glass inserts.
Wall stacker cabinet with 2 glass doors and matching color cabinet interior. This cabinet is available with the glass doors only. It does not include glass inserts.
Wall stacker cabinet with 2 glass doors and matching color cabinet interior. This cabinet is available with the glass doors only. It does not include glass inserts.
Diagonal wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion. The visible cabinet front part is approximately 17" wide.
Diagonal wall stacker cabinet with 1 glass door and matching color cabinet interior. This cabinet is available with the glass door only. It does not include a glass insert. The glass door comes without a mullion. The visible cabinet front part is approximately 17" wide.
Base cabinet with 1 full door. This cabinet can be modified into a base tray or spice cabinet. The additional hardware is available in the Cabinet Organizers section.
Base cabinet with 1 door, 1 drawer, and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The waste container pullout hardware is available in the Cabinet Organizers section.
Base cabinet with 1 door, 1 drawer, and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The waste container pullout hardware is available in the Cabinet Organizers section.
Base cabinet with 1 full height door and 1 shelf. This cabinet can be modified into a base tray or spice cabinet. The additional hardware is available in the Cabinet Organizers section.
Base cabinet with 1 full height door and 1 shelf. This cabinet can be modified into a base tray or spice cabinet. The additional hardware is available in the Cabinet Organizers section.
Base cabinet with 1 full height door and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The additional hardware is available in the Cabinet Organizers section.
Base cabinet with 1 full height door and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The additional hardware is available in the Cabinet Organizers section.
One of the greatest features Charleston Cream cabinet line has to offer is the use of UV coating as a finish. The end result is a hard surface that resists moisture and light fading. These cabinets are designed for functionality and style. It will be a perfect choice for any kitchen renovation project.
